The Right Entry Point for Every Property.
A quality gate is the centerpiece of any fence installation. Circle A Fences offers a full range of residential and commercial gates — from simple walk-through pedestrian gates to heavy-duty industrial drive gates and cantilever slide gates for large commercial openings. All gates are available with the hardware necessary for a complete installation.
Quickly Find
Pedestrian Gates — Residential Chain Link
Our residential walk gates are built with 1⅝” O.D. frames and come complete with all required installation hardware. Standard sizes are listed below; other sizes are available upon request.
Single Walk Gates
| Height | Opening |
|---|---|
| 4′ | 3′ |
| 4′ | 3½’ |
| 4′ | 4′ |
| 5′ | 3′ |
| 5′ | 3½’ |
| 5′ | 4′ |
| 6′ | 3′ |
| 6′ | 3½’ |
| 6′ | 4′ |
Driveway Gates — Residential Chain Link
Double drive gates provide a complete driveway opening in standard chain link construction. Hardware included.
| Height | Opening |
|---|---|
| 4′ | 8′ |
| 4′ | 10′ |
| 4′ | 12′ |
| 4′ | 14′ |
| 4′ | 16′ |
| 5′ | 10′ |
| 5′ | 12′ |
| 5′ | 14′ |
| 5′ | 16′ |
| 6′ | 10′ |
| 6′ | 12′ |
| 6′ | 14′ |
| 6′ | 16′ |
| Graded (raked) gates available upon request. Other sizes made upon request. |
Industrial Single Gates
Our industrial single gates are built with heavy-gauge frame material for high-traffic commercial and industrial applications. Available in light-weight (L/W) and full-weight (F/W) construction with 1⅞” or 2″ frames. Heights from 4′ to 10′ and widths from 3′ to 10′ wide. Hardware not included; see our gate fittings for available options. Contact us for a quote.
Industrial Double Drive Gates
Double drive gates provide wide openings for vehicle access at commercial and industrial facilities. Available in light-weight (L/W) and full-weight (F/W) construction with 1⅞” or 2″ frames. Heights from 4′ to 10′ and total openings from 10′ to 30′ wide. Roll gates use the same construction; add a roll gate kit and 1⅞” Sch. 40 pipe track. Hardware not included. Contact us for a quote.
Cantilever Slide Gates
Cantilever gates are the premier choice for high-use commercial and industrial entrances where a swing gate isn’t practical. They slide horizontally on a track system, requiring no ground track across the driveway — ideal for high-traffic areas, uneven ground, or applications where a clear drive surface is essential.
Our cantilever gates are built to customer specifications and are available with or without barbed wire arm extensions. Frame specifications: top and bottom members 2½” O.D., vertical members 2″ O.D., horizontal and diagonal members 1⅞” O.D.
Available heights from 4′ to 12′ and openings from 10′ to 30′. Prices include caps and tail braces; rollers, latches, and hardware are not included. For double drive configurations, order two gates each at half the total opening size. Contact us for a quote.
Post Size Recommendations for Cantilever Gates
for Cantilever Gates
| Maximum Gate Width | Recommended Post Size |
|---|---|
| Up to 15′ | 3″ Sch. 40 Pipe |
| Larger than 15′ | 4″ Sch. 40 Pipe |
Automatic Gates
We can integrate automatic gate operators with virtually any gate style — swing, slide, or cantilever. Automatic systems are ideal for residential driveways, commercial facilities, and anywhere that frequent access without manual operation is a priority. Contact us to discuss operator options, access control systems, and installation.
All gate prices are subject to change without notice. Custom sizes are available — contact us for a quote.
